ASUS Prime X870-P WiFi AMD AM5 X870
| Category | Specification Details |
|---|---|
| Brand / Model | ASUS Prime X870-P WIFI |
| CPU Socket | AMD Socket AM5 for Ryzen™ 9000, 8000 & 7000 Series |
| Chipset | AMD X870 |
| Power Solution | 14+2+1 80A DrMOS Power Stages | 8-Layer PCB | ProCool Connectors |
| Memory Support | 4 x DIMM, Max. 256GB, DDR5 (Up to 8000+ MT/s OC) | EXPO™ & AEMP Support |
| Graphics Output | 1 x HDMI™ 2.1 (4K@60Hz) | 2 x USB4® Type-C (DP Alt Mode 1.4a) |
| Expansion Slots | 1 x PCIe 5.0 x16 (Ryzen 9000/7000) | 3 x PCIe 4.0 x16 (x1 mode) |
| Storage | 4 x M.2 Slots (1x PCIe 5.0 x4, 2x PCIe 4.0 x4, 1x PCIe 3.0 x2) | 2 x SATA 6Gb/s |
| Networking | Wi-Fi 7 (802.11be) 2x2 | Bluetooth® v5.4 | Realtek 2.5Gb Ethernet |
| Rear USB Ports | 2 x USB4® (40Gbps) | 1 x USB 10Gbps | 3 x USB 5Gbps | 4 x USB 2.0 |
| Front USB Ports | 1 x USB 10Gbps (Type-C) | 1 x USB 5Gbps header | 2 x USB 2.0 headers |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| DIY Friendly | PCIe Slot Q-Release | M.2 Q-Latch | BIOS FlashBack™ | Pre-mounted I/O Shield |
| Form Factor | ATX (12" x 9.6") |
$80.16
Original: $267.20
-70%ASUS Prime X870-P WiFi AMD AM5 X870—
$267.20
$80.16Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
| Category | Specification Details |
|---|---|
| Brand / Model | ASUS Prime X870-P WIFI |
| CPU Socket | AMD Socket AM5 for Ryzen™ 9000, 8000 & 7000 Series |
| Chipset | AMD X870 |
| Power Solution | 14+2+1 80A DrMOS Power Stages | 8-Layer PCB | ProCool Connectors |
| Memory Support | 4 x DIMM, Max. 256GB, DDR5 (Up to 8000+ MT/s OC) | EXPO™ & AEMP Support |
| Graphics Output | 1 x HDMI™ 2.1 (4K@60Hz) | 2 x USB4® Type-C (DP Alt Mode 1.4a) |
| Expansion Slots | 1 x PCIe 5.0 x16 (Ryzen 9000/7000) | 3 x PCIe 4.0 x16 (x1 mode) |
| Storage | 4 x M.2 Slots (1x PCIe 5.0 x4, 2x PCIe 4.0 x4, 1x PCIe 3.0 x2) | 2 x SATA 6Gb/s |
| Networking | Wi-Fi 7 (802.11be) 2x2 | Bluetooth® v5.4 | Realtek 2.5Gb Ethernet |
| Rear USB Ports | 2 x USB4® (40Gbps) | 1 x USB 10Gbps | 3 x USB 5Gbps | 4 x USB 2.0 |
| Front USB Ports | 1 x USB 10Gbps (Type-C) | 1 x USB 5Gbps header | 2 x USB 2.0 headers |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| DIY Friendly | PCIe Slot Q-Release | M.2 Q-Latch | BIOS FlashBack™ | Pre-mounted I/O Shield |
| Form Factor | ATX (12" x 9.6") |
